Battery condition is important. No regulator can make up for a bad or weak battery. If in doubt charge your battery and have it load tested, or simply replace it.
ALWAYS START WITH A FULLY CHARGED BATTERY!
Technical Details
Dimensions:
Width: 110 mm
Length: 80 mm
Height: 28 mm
Distance between fixation holes center to center: 84 mm
Other specifications:
Number of plugs: 2
Number of pins: 4
Number of wires: 0
Minimum Charging Voltage: 14.5 V +- 0.5 V
Maximum Charging Current: 50 A / 500 W
Open Circuit Voltage: < 15 V
Operation Temperature: -20°C to 85°C
Part Application/Fitment
| Model |
Code |
Year |
Manufacturer |
Engine |
| KAF 400 Mule SX EFI |
RMS020-107175 |
2019 |
Kawasaki |
|
| KAF 400 Mule SX EFI |
RMS020-107175 |
2020 |
Kawasaki |
|
| KAF 400 Mule SX EFI |
RMS020-107175 |
2021 |
Kawasaki |
|
Interchanges/Cross References
| Model |
Code |
| 21066-0767 |
Kawasaki |
