For full application / interchanges listing, please see our part Application / Fitment section below
Dimensions:
Height: 27 mm
Length: 22 mm
Width: 24 mm
Bracket center to center: 34 mm
Wires length : 980 mm
Other specifications:
Number of wires : 2
Wire to wire resistance:
= 250 ohms +/-20%
| Model | Code | Year | Manufacturer | Engine |
| TRX 420 Rancher FE | RM00135 | 2007 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2008 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2007 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2008 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2009 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2010 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2011 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2012 | Honda | |
| TRX 420 Rancher FE | RM00135 | 2013 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2007 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2008 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2007 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2008 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2009 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2010 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2011 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2012 | Honda | |
| TRX 420 Rancher FM | RM00135 | 2013 | Honda | |
| TRX 420 Rancher FPE | RM00135 | 2009 | Honda | |
| TRX 420 Rancher FPE | RM00135 | 2010 | Honda | |
| TRX 420 Rancher FPE | RM00135 | 2011 | Honda | |
| TRX 420 Rancher FPE | RM00135 | 2012 | Honda | |
| TRX 420 Rancher FPE | RM00135 | 2013 | Honda | |
| TRX 420 Rancher FPM | RM00135 | 2009 | Honda | |
| TRX 420 Rancher FPM | RM00135 | 2010 | Honda | |
| TRX 420 Rancher FPM | RM00135 | 2011 | Honda | |
| TRX 420 Rancher FPM | RM00135 | 2012 | Honda | |
| TRX 420 Rancher FPM | RM00135 | 2013 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2007 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2008 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2009 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2010 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2011 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2012 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2013 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2007 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2008 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2009 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2010 | Honda | |
| TRX 420 Rancher TE | RM00135 | 2011 | Honda | |
| Model | Code |
| 31120-HP0-A01 | Honda |
| 31120-HP1-003 | Honda |
| 31120-HP1-601 | Honda |
| 31120-HP5-601 | Honda |
| 31120-HP5-A51 | Honda |
| 31120-HR0-F01 | Honda |
